YL-10B-300Nm Dynamic Torque Sensor, Torque Sensor for Pneumatic Torque Wrench

In the fields of industrial assembly, mechanical manufacturing, and precision machining, torque accuracy serves as a core indicator to guarantee product assembly quality and stable equipment operation. As efficient and convenient fastening tools, pneumatic torque wrenches are widely used in automobile manufacturing, hardware assembly, engineering machinery and other scenarios. However, long-term operation will cause torque deviation, power attenuation and accuracy drift of the wrenches, making regular accurate calibration and detection indispensable. The YL-10B-300Nm Dynamic Torque Sensor, a special detection device tailored for pneumatic torque wrenches, has become a core supporting device for industrial torque calibration by virtue of its high precision, excellent stability and real-time dynamic detection capability.

1. Product Core Positioning: Professional Precision Detection Device for Pneumatic Torque Wrenches

Launched by Youzhongli, the YL-10B-300Nm dynamic torque sensor is a high-performance dynamic sensing device with a rated range of 0-300Nm, specially designed for pneumatic torque wrench torque detection. Different from static torque sensors that only capture steady-state data, this device focuses on real-time dynamic data acquisition, perfectly adapting to the high-speed impact and dynamic fastening working characteristics of pneumatic torque wrenches. It effectively solves the common industry pain points of traditional detection equipment, such as failure to capture dynamic torque, large data deviation and detection delay.

With a full detection range of 0 to 300Nm, the sensor is perfectly compatible with most small and medium-sized pneumatic torque wrenches on the market. It can conduct all-round and high-precision detection on the dynamic working torque during bolt and nut fastening, as well as the no-load, load and peak torque of wrenches. It is an essential professional device for factory inspection, daily calibration and maintenance quality inspection of pneumatic torque wrenches.

2. Core Technical Advantages for Industrial High-Precision Detection

2.1 Real-Time Dynamic Data Acquisition, Restoring Actual Working Conditions Truly

The working process of pneumatic torque wrenches is an instantaneous dynamic impact process. Traditional static detection equipment can only measure steady-state torque and fails to capture instantaneous peak torque, resulting in a large deviation between detection data and actual working conditions. Equipped with high-precision dynamic sensing chips, the YL-10B-300Nm dynamic torque sensor can collect torque data at millisecond level. It completely records the full-process torque changes, peak torque and steady-state torque of wrench operation, truly restoring the actual working conditions and ensuring high reference value of detection data.

2.2 High Precision and Low Drift, Ensuring Stable and Reliable Detection Results

Adopting high-quality elastomer and precision strain gauge technology, the sensor undergoes strict temperature compensation and linear calibration before leaving the factory. It features high accuracy, low temperature drift and excellent repeatability. No data drift occurs during long-term continuous detection. With strong vibration resistance and anti-interference ability, it can adapt to complex workshop industrial environments, avoid detection errors caused by environmental factors, and meet the accuracy standards of industrial quality inspection and third-party metering calibration.

2.3 Special Adaptive Design, Easy Installation and Operation

Optimized according to the structural characteristics and working modes of pneumatic torque wrenches, the sensor improves the connection structure and stress mode. It can be quickly matched with various straight-handle and bent-handle pneumatic torque wrenches without complex adapter accessories. Compact in structure, compression-resistant and durable, it supports multiple application modes including fixed station detection and portable sampling inspection. The operation is simple and requires no professional technicians to complete torque detection and calibration efficiently, greatly improving the overall quality inspection efficiency of equipment.

2.4 Wide Range and Strong Universality

The 0-300Nm golden range covers more than 80% of the application scenarios of small and medium-sized pneumatic torque wrenches in industrial production. It is widely applicable to automobile parts assembly, hardware tool production, equipment maintenance, rail transit parts processing and other fields, meeting the torque detection and calibration demands of most conventional pneumatic fastening equipment in the industry.
